U3MR331-WDR 1/3" AR0331 3MP USB2.0 Camera board H.264 YUY2 MJPEG
U3MR331-WDR 1/3" AR0331 3MP USB2.0 Camera board H.264 YUY2 MJPEG
Catalog:
SKU: U3MR331-WDR
Sensor:
Resolution:
$55.00
Price: $42.30 - $55.00
Weight: 0.05 kg
Dimensions: 3.2 cm × 3.2 cm × 26 cm
| Product number | |||
| Sensor | AR0331 | ||
| MAX effective pixels | 2592 * 1944 | ||
| Pixel Size | 2.2um x 2.2um | ||
| Sensor Size | 1/3" | ||
| Output parameters | video format | Rosolution | Max Frame rate |
| H.264/YUY2/MJPEG(default) | 2052 * 1536 | 15fps | |
| H.264/YUY2/MJPEG(default) | 1920 * 1080 | 30fps | |
| H.264/YUY2/MJPEG(default) | 1280 * 720 | 30fps | |
| H.264/YUY2/MJPEG(default) | 640 * 480 (default) | 30fps | |
| focusing | Auto | ||
| max S/N ratio | 39dB | ||
| dynamic range | 100dB | ||
| Sensitivity | 2.0V/Lux-sec@550nm | ||
| Min illumination | 0.05lux | ||
| Interface type | USB2.0 | ||
| Adjustable parameter | Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White Balance, Exposure | ||
| White Balance | Automatic / Manual | ||
| Exposure Control | Automatic / Manual | ||
| Voltage | DC 5V | ||
| Electric current | 140mA ~ 200mA | ||
| Main chip | DSP/SENSOR/FLASH | ||
| AEC | Support | ||
| AEB | Support | ||
| AGC | Support | ||
| PCBA Size | Customized | ||
| Storage temperature | -20°C to 80°C | ||
| working temperature | -20°C to 70°C | ||
| USB Wire rod | Customized 26cm / 1.5M / 3M / 5M | ||
| Board Size | 32mm x 32mm | ||
| System support | WinXP/Vista/Win7/Win8/Win10 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC | ||
| Lens | 2.45mm / 2.8mm / 3.6mm / 4.3mm / 6mm / 8mm / 12mm (optional) | ||
| Mic | Dual Digital Mic | ||
