Manufacturer 12MP 1" USB scientific CMOS industrial camera module
Manufacturer 12MP 1" USB scientific CMOS industrial camera module
SKU: U3CS12MRS-15FC
Resolution:
$1,200.00
Price: $1043.50 - $1200.00
Weight: 140 g
Dimensions: 39 mm × 44 mm × 44 mm
Manufacturer 12MP 1" USB scientific CMOS industrial camera module
Parameter
| Model | U3CS12MRS-15FC | ||
| Pixels | 12MP(color) | ||
| Sensor Size | 1" CMOS | ||
| Pixel Size | 3.1μm x 3.1μm | ||
| Max Resolution | 4096(H) x 3072(V) | ||
| Frame rate | 15fps | ||
| BIN | 2x2/3x3/4x4 | ||
| ROI | Any ROI | ||
| Shutter | Rolling shutter | ||
| Exposure Time | 41μs ～ 10s | ||
| Spectral Range (nm) | 380nm~1050nm | ||
| Image data format | 8bit/10bit RAW | ||
| Working Mode | Continuous output/software trigger | ||
| Software Interface | DirectShow/Twain | ||
| On-board buffer | 64MB | ||
| Exposure | Manual / Auto/ Area Exposure | ||
| White Balance | Manual/One-time/Automatic/Area (Only for color camera) | ||
| Image processing | Speed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/ 2D,3D Noise Reduction/（Saturation only for color camera） | ||
| User Memory | 32K bit | ||
| Product ID | user-defined | ||
| Systems | Windows XP (32bit);Windows 7 (32bit/64bit);Windows 8 (32bit/64bit);Windows 8.1 (32bit/64bit)/Window 10(64bit) | ||
| Data Interface | USB3.0 Type-B | ||
| Transmission Distance | 5 meters | ||
| Trigger Port | N/A | ||
| Rated Power(W) | <2.0W | ||
| Working Temperature | 0~50℃ | ||
| Working Humidity | 10~90%RH( No condensation) | ||
| lens Mount | C / CS Mount | ||
| Product Size (mm) | 44mm * 44mm * 39mm（Exclude lens extension ring） | ||
| Weight | Approx 140g | ||
Built-in 32 MB buffer ensure image transmission more stable and faster
Plug and play interface
