12MP@15PFS Mono 1" 3.1um rolling shutter CMOS USB3.0 Industrial camera

12MP@15PFS Mono 1" 3.1um rolling shutter CMOS USB3.0 Industrial camera

SKU: U3CS12M-15FM

Aperture:

Mount Type:

Resolution:

$1,680.00
Price: $1460.90 - $1680.00
Weight: 0.3 kg

12MP@15PFS Mono 1" CMOS USB3.0 Industrial camera

Parameter

ModelU3CS12M-15FM
Pixels12MP(Mono)
Sensor Size1" CMOS
Pixel Size3.1μm x 3.1μm
Max Resolution4096(H) x 3072(V)
Frame rate15fps
BIN2x2/3x3/4x4
ROIAny ROI
ShutterRolling shutter
Exposure Time100μs ~ 10s
Spectral Range (nm)380nm~1050nm
Image data format8bit/10bit RAW
Working ModeContinous output/software trigger
Software InterfaceDirectShow/Twain
On-board buffer64MB
ExposureManual / Auto/ Area Exposure
White BalanceManual/One-time/Automatic/Area (Only for color camera)
Image processingSpeed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/
2D,3D Noise Reduction/(Saturation only for color camera)
User Memory32K bit
Product IDuser-defined
SystemsWindows XP (32bit); Windows 7 (32bit/64bit); Windows 8 (32bit/64bit);
Windows 8.1 (32bit/64bit)/Window 10(64bit)
Data InterfaceUSB3.0 Type-B
Transmission Distance5 meters
Trigger PortN/A
Rated Power(W)<2.0W
Working Temperature0~50°C
Working Humidity10~90%RH( No condensation)
lens MountC / CS Mount
Product Size (mm)44mm * 44mm * 39mm(Exclude lens extension ring)
WeightApprox 140g

Built-in 32 MB buffer ensure image transmission more stable and faster

Plug and play interface
