1.67um Aptina 1/2.3" CMOS MT9J003 10MP Medical USB C-Mount Camera
1.67um Aptina 1/2.3" CMOS 10MP Medical USB C-Mount Camera
Model No | U2CV10M-3FC |
SENSOR Model | MT9J003 |
SENSOR Size | 1/2.3" CMOS (Color) |
Efficient Pixels | 3664（H）×2748（V） |
Pixel Size | 1.67μm×1.67μm |
Scan type | Progressive Scan |
Max Resolution/Frame | Max resolution:3664*2748 Frame rate:3.2FPS。Support ROI,(ROI resolution should be times of 4）,Minimum resolution:256*256。 |
Image format | 8bit RAW |
Exposure time | 0.1-3000ms； |
Gain | 1x～8x |
Systems | WINDOSW XP 32bit, WIN7/WIN8/WIN10 32bit and 64bit |
Product Series Number | supported |
FW Remote Update | supported |
IO Requirement | 7 software controlled GPOs,included 2 GPO opto-coupler outputs |
Rate Power(W) | <1W |
USB Interface | 5PIN WAFER |
IO Connector | 10PIN WAFER |
Working Temperature | 0℃~50℃ |
Working Humidity | 10%~90% (No Condensation) |
PCB Size | Single board,39*39*60 |
API Functions | 1) Gain,Exposure Time,Resolution,Speed,Black Level. 2) GPO outputs control |
Accessories | 130mm USB2.0 Cable；130mm IO Cable。 |
MICROSCOPY CAMERA CBYE SERIES:
Features:
High compatibility;More stable transmission.
TWAIN and DirectShow as software interface.
1MP~10MP Digital Camera.Better image performance in color.
Unique design for microscopy applications.
Dustproof rubber cover can ensure sensor surfaceclean.
Parameters:
Applications:
